一、安装和简介

a) download url

b) Reveal 使用的方法有两种: Static Library Intefration, Dynamic Library Intefration。(我们使用 Dynamic Library Intefration)

二、Dynamic Library Intefration

a) 打开 Reveal -> Help -> Show Reveal Library In Finder, copy libReveal.dylib 到目标 app 的 Documents 目录。(我使用的是新浪的天气通)

b) 创建 RevealUtil.h 和 RevealUtil.m，来自《iOS应用逆向工程》。

RevealUtil.h

#import <Foundation/Foundation.h>

@interface RevealUtil : NSObject {

    @private

        void* revealLib;

}

- (void)startReveal;

- (void)stopReveal;

@end

RevealUtil.m

#import "RevealUtil.h"

#import <dlfcn.h>

@implementation RevealUtil

- (void)startReveal {

    NSString* revealLibName = @"libReveal.dylib";

    NSString* documentDirectory = NSSearchPathForDirectoriesInDomains(NSDocumentDirectory, NSUserDomainMask, YES)[0];

    NSString* dyLibPath = [documentDirectory stringByAppendingPathComponent:revealLibName];

    revealLib = dlopen([dyLibPath cStringUsingEncoding:NSUTF8StringEncoding], RTLD_NOW);

    if (revealLib == nil) {

        char *error = dlerror();

        NSLog(@"dlopen error: %s", error);

    } else {

        [[NSNotificationCenter defaultCenter] postNotificationName:@"IBARevealRequestStart" object:self];

    }

}

- (void)stopReveal {

    if (revealLib != nil) {

        [[NSNotificationCenter defaultCenter] postNotificationName:@"IBARevealRequestStop" object:self];

        if (dlclose(revealLib) == 0) {

            revealLib = nil;

        } else {

            char *error = dlerror();

            NSLog(@"Reveal Library could not be unloaded: %s", error);

        }

    }

}

@end
