Android单元测试与模拟测试详解

dependencies {
// Required -- JUnit 4 framework，用于单元测试，google官方推荐
testCompile 'junit:junit:4.12'
// Optional -- Mockito framework，用于模拟架构，google官方推荐
// http://www.manongjc.com/article/1546.html
testCompile 'org.mockito:mockito-core:1.10.19'
}

dependencies {
androidTestCompile 'com.android.support:support-annotations:23.0.1'
androidTestCompile 'com.android.support.test:runner:0.4.1'
androidTestCompile 'com.android.support.test:rules:0.4.1'
// Optional -- Hamcrest library
androidTestCompile 'org.hamcrest:hamcrest-library:1.3'
// Optional -- UI testing with Espresso
// http://www.manongjc.com/article/1546.html
androidTestCompile 'com.android.support.test.espresso:espresso-core:2.2.1'
// Optional -- UI testing with UI Automator
androidTestCompile 'com.android.support.test.uiautomator:uiautomator-v18:2.1.1'
}

import static android.support.test.espresso.Espresso.onView;
import static android.support.test.espresso.action.ViewActions.click;
import static android.support.test.espresso.assertion.ViewAssertions.matches;
import static android.support.test.espresso.matcher.ViewMatchers.isDisplayed;
import static android.support.test.espresso.matcher.ViewMatchers.withId;// 对于Id为R.id.my_view的View: 触发点击，检测是否显示
onView(withId(R.id.my_view)).perform(click())
.check(matches(isDisplayed()));
// 对于文本打头是"ABC"的View: 检测是否没有Enable
onView(withText(startsWith("ABC"))).check(matches(not(isEnabled()));
// 按返回键
pressBack();
// 对于Id为R.id.button的View: 检测内容是否是"Start new activity"
// http://www.manongjc.com/article/1537.html
onView(withId(R.id.button)).check(matches(withText(("Start new activity"))));
// 对于Id为R.id.viewId的View: 检测内容是否不包含"YYZZ"
onView(withId(R.id.viewId)).check(matches(withText(not(containsString("YYZZ")))));
// 对于Id为R.id.inputField的View: 输入"NewText"，然后关闭软键盘
onView(withId(R.id.inputField)).perform(typeText("NewText"), closeSoftKeyboard());
// 对于Id为R.id.inputField的View: 清除内容
onView(withId(R.id.inputField)).perform(clearText());

@RunWith(AndroidJUnit4.class)
public class SecondActivityTest {
@Rule
public ActivityTestRule<SecondActivity> rule =
new ActivityTestRule(SecondActivity.class, true,
// 这个参数为false，不让SecondActivity自动启动
// 如果为true，将会在所有@Before之前启动，在最后一个@After之后关闭
false);
@Test
public void demonstrateIntentPrep() {
Intent intent = new Intent();
intent.putExtra("EXTRA", "Test");
// 启动SecondActivity并传入intent
rule.launchActivity(intent);
// 对于Id为R.id.display的View: 检测内容是否是"Text"
// http://www.manongjc.com/article/1532.html
onView(withId(R.id.display)).check(matches(withText("Test")));
}
}

// 通过实现IdlingResource，block住当非空闲的时候，当空闲时进行检测，非空闲的这段时间处理异步事情
public class IntentServiceIdlingResource implements IdlingResource {
ResourceCallback resourceCallback;
private Context context; public IntentServiceIdlingResource(Context context) { this.context = context; } @Override public String getName() { return IntentServiceIdlingResource.class.getName(); } @Override public void registerIdleTransitionCallback( ResourceCallback resourceCallback) { this.resourceCallback = resourceCallback; } @Override public boolean isIdleNow() {
// 是否是空闲
// 如果IntentService 没有在运行，就说明异步任务结束，IntentService特质就是启动以后处理完Intent中的事务，理解关闭自己
// http://www.manongjc.com/article/1531.html
boolean idle = !isIntentServiceRunning();
if (idle && resourceCallback != null) {
// 回调告知异步任务结束
resourceCallback.onTransitionToIdle();
}
return idle;
} private boolean isIntentServiceRunning() {
ActivityManager manager = (ActivityManager) context.getSystemService(Context.ACTIVITY_SERVICE);
// Get all running services
List<ActivityManager.RunningServiceInfo> runningServices = manager.getRunningServices(Integer.MAX_VALUE);
// check if our is running
for (ActivityManager.RunningServiceInfo info : runningServices) {
if (MyIntentService.class.getName().equals(info.service.getClassName())) {
return true;
}
}
return false;
}
}// 使用IntentServiceIdlingResource来测试，MyIntentService服务启动结束这个异步事务，之后的结果。
@RunWith(AndroidJUnit4.class)
public class IntegrationTest { @Rule
public ActivityTestRule rule = new ActivityTestRule(MainActivity.class);
IntentServiceIdlingResource idlingResource; @Before
public void before() {
Instrumentation instrumentation = InstrumentationRegistry.getInstrumentation();
Context ctx = instrumentation.getTargetContext();
idlingResource = new IntentServiceIdlingResource(ctx);
// 注册这个异步监听
Espresso.registerIdlingResources(idlingResource); }
@After
public void after() {
// 取消注册这个异步监听
Espresso.unregisterIdlingResources(idlingResource); } @Test
public void runSequence() {
// MainActivity中点击R.id.action_settings这个View的时候，会启动MyIntentService
onView(withId(R.id.action_settings)).perform(click());
// 这时候IntentServiceIdlingResource#isIdleNow会返回false，因为MyIntentService服务启动了
// 这个情况下，这里会block住.............
// 直到IntentServiceIdlingResource#isIdleNow返回true，并且回调了IntentServiceIdlingResource#onTransitionToIdle
// 这个情况下，继续执行，这时我们就可以测试异步结束以后的情况了。
onView(withText("Broadcast")).check(matches(notNullValue()));
}
}

// 定义
public static Matcher<View> withItemHint(String itemHintText) {
checkArgument(!(itemHintText.equals(null)));
return withItemHint(is(itemHintText));
}public static Matcher<View> withItemHint(final Matcher<String> matcherText) {
checkNotNull(matcherText);
return new BoundedMatcher<View, EditText>(EditText.class) { @Override
public void describeTo(Description description) {
description.appendText("with item hint: " + matcherText);
} @Override
protected boolean matchesSafely(EditText editTextField) {
// 取出hint，然后比对下是否相同
// http://www.manongjc.com/article/1524.html
return matcherText.matches(editTextField.getHint().toString());
}
};
}// 使用
onView(withItemHint("test")).check(matches(isDisplayed()));

import static org.assertj.core.api.Assertions.*;// 断言: view是GONE的
assertThat(view).isGone();MyClass test = new MyClass("Frodo");
MyClass test1 = new MyClass("Sauron");
MyClass test2 = new MyClass("Jacks");List<MyClass> testList = new ArrayList<>();
testList.add(test);
testList.add(test1);// 断言: test.getName()等于"Frodo"
assertThat(test.getName()).isEqualTo("Frodo");
// 断言: test不等于test1并且在testList中
// http://www.manongjc.com/article/1519.html
assertThat(test).isNotEqualTo(test1)
.isIn(testList);
// 断言: test.getName()的字符串，是由"Fro"打头，以"do"结尾，忽略大小写会等于"frodo"
assertThat(test.getName()).startsWith("Fro")
.endsWith("do")
.isEqualToIgnoringCase("frodo");
// 断言: testList有2个数据，包含test，test1，不包含test2
assertThat(list).hasSize(2)
.contains(test, test1)
.doesNotContain(test2);// 断言: 提取testList队列中所有数据中的成员变量名为name的变量，并且包含name为"Frodo"与"Sauron"
// 并且不包含name为"Jacks"
assertThat(testList).extracting("name")
.contains("Frodo", "Sauron")
.doesNotContain("Jacks");

import static org.hamcrest.MatcherAssert.assertThat;
import static org.hamcrest.Matchers.is;
import static org.hamcrest.Matchers.equalTo;// 断言: a等于b
assertThat(a, equalTo(b));
assertThat(a, is(equalTo(b)));
assertThat(a, is(b));
// 断言: a不等于b
assertThat(actual, is(not(equalTo(b))));List<Integer> list = Arrays.asList(5, 2, 4);
// 断言: list有3个数据
assertThat(list, hasSize(3));
// 断言: list中有5,2,4，并且顺序也一致
assertThat(list, contains(5, 2, 4));
// 断言: list中包含5,2,4
assertThat(list, containsInAnyOrder(2, 4, 5));
// 断言: list中的每一个数据都大于1
// http://www.manongjc.com/article/1507.html
assertThat(list, everyItem(greaterThan(1)));
// 断言: fellowship中包含有成员变量"race"，并且其值不是ORC
assertThat(fellowship, everyItem(hasProperty("race", is(not((ORC))))));
// 断言: object1中与object2相同的成员变量都是相同的值
assertThat(object1, samePropertyValuesAs(object2));Integer[] ints = new Integer[] { 7, 5, 12, 16 };
// 断言: 数组中包含7,5,12,16
assertThat(ints, arrayContaining(7, 5, 12, 16));

// 自定义
import org.hamcrest.Description;
import org.hamcrest.TypeSafeMatcher;public class RegexMatcher extends TypeSafeMatcher<String> {
private final String regex; public RegexMatcher(final String regex) { this.regex = regex; }
@Override
public void describeTo(final Description description) { description.appendText("matches regular expression=`" + regex + "`"); } @Override
public boolean matchesSafely(final String string) { return string.matches(regex); } // 上层调用的入口
public static RegexMatcher matchesRegex(final String regex) {
return new RegexMatcher(regex);
}
}// 使用
String s = "aaabbbaaa";
assertThat(s, RegexMatcher.matchesRegex("a*b*a"));

// import如相关类
import static org.mockito.Mockito.mock;
import static org.mockito.Mockito.verify;// 创建一个Mock的对象
MyClass test = mock(MyClass.class);// 当调用test.getUniqueId()的时候返回43
when(test.getUniqueId()).thenReturn(43);
// 当调用test.compareTo()传入任意的Int值都返回43
when(test.compareTo(anyInt())).thenReturn(43);
// 当调用test.compareTo()传入的是Target.class类型对象时返回43
when(test.compareTo(isA(Target.class))).thenReturn(43);
// 当调用test.close()的时候，抛IOException异常
doThrow(new IOException()).when(test).close();
// 当调用test.execute()的时候，什么都不做
doNothing().when(test).execute();// 验证是否调用了两次test.getUniqueId()
// http://www.manongjc.com/article/1503.html
verify(test, times(2)).getUniqueId();
// 验证是否没有调用过test.getUniqueId()
verify(test, never()).getUniqueId();
// 验证是否至少调用过两次test.getUniqueId()
verify(test, atLeast(2)).getUniqueId();
// 验证是否最多调用过三次test.getUniqueId()
verify(test, atMost(3)).getUniqueId();
// 验证是否这样调用过:test.query("test string")
verify(test).query("test string");// 通过Mockito.spy() 封装List对象并返回将其mock的spy对象
List list = new LinkedList();
List spy = spy(list);// 指定spy.get(0)返回"foo"
doReturn("foo").when(spy).get(0);assertEquals("foo", spy.get(0));

import org.mockito.ArgumentCaptor;
import org.mockito.Captor;
import static org.junit.Assert.assertEquals;@Captor
private ArgumentCaptor<Integer> captor;@Test
public void testCapture(){
MyClass test = mock(MyClass.class); test.compareTo(3, 4);
verify(test).compareTo(captor.capture(), eq(4)); assertEquals(3, (int)captor.getValue()); // 需要特别注意，如果是可变数组(vargars)参数，如方法 test.doSomething(String... params)
// 此时是使用ArgumentCaptor<String>，而非ArgumentCaptor<String[]>
ArgumentCaptor<String> varArgs = ArgumentCaptor.forClass(String.class);
test.doSomething("param-1", "param-2");
verify(test).doSomething(varArgs.capture()); // 这里直接使用getAllValues()而非getValue()，来获取可变数组参数的所有传入参数
assertThat(varArgs.getAllValues()).contains("param-1", "param-2");
}

@RunWith(PowerMockRunner.class)
@PrepareForTest({StaticClass1.class, StaticClass2.class})
public class MyTest { @Test
public void testSomething() {
// mock完静态类以后，默认所有的方法都不做任何事情
mockStatic(StaticClass1.class);
when(StaticClass1.getStaticMethod()).andReturn("anything"); // 验证是否StaticClass1.getStaticMethod()这个方法被调用了一次
verifyStatic(time(1));
StaticClass1.getStaticMethod(); when(StaticClass1.getStaticMethod()).andReturn("what ever"); // 验证是否StaticClass2.getStaticMethod()这个方法被至少调用了一次
verifyStatic(atLeastOnce());
StaticClass2.getStaticMethod(); // 通过任何参数创建File的实力，都直接返回fileInstance对象
whenNew(File.class).withAnyArguments().thenReturn(fileInstance);
}
}

class FooWraper{
void someMethod() {
Foo.someStaticMethod();
}
}

@Test
public void doSomethingTests(){
// 获取Application对象
Application application = RuntimeEnvironment.application; // 启动WelcomeActivity
WelcomeActivity activity = Robolectric.setupActivity(WelcomeActivity.class);
// 触发activity中Id为R.id.login的View的click事件
// http://www.manongjc.com/article/1502.html
activity.findViewById(R.id.login).performClick(); Intent expectedIntent = new Intent(activity, LoginActivity.class);
// 在activity之后，启动的Activity是否是LoginActivity
assertThat(shadowOf(activity).getNextStartedActivity()).isEqualTo(expectedIntent);
}
}
